LED recessed downlights COB (Chip On Board) CYRA+

C+S-1-1-NW-80-60-11

CYRA+ S Refit LED-Downlight,On/Off,Refl.,gl. starr,rd,230V,18/24W,IP20,4000K,CRI80,RAL9016,60°

Article nr.: C+S-1-1-NW-80-60-11

Downlight for indoor use, IP20 · Front ring of galvanised sheet steel, powder-coated · COB module carrier and lens interchangeable · Faceted trumpet reflector made of ultra-pure aluminium, highly specular · Housing colour: RAL9016 · High-quality PMMA optic for precise light control and very good glare control · Homogeneous symmetrical illumination, UGR<19 · Beam angle: 60° · Power: 18 or 24 W · Light colour: 4000 K · Luminous flux: 2580 or 3540 lm · CRI: >80 · Lifespan L70B50: >= 60,000 h · Lifespan L80B10: >= 50,000 h · Input voltage: 220-240 V AC, 50/60 Hz · Protection class II · Installation depth: 85 mm · Ceiling cut-out: 175-195 mm · Outer diameter: 207 mm · Tool-free installation in the ceiling with tension springs that adapt to the ceiling thickness · (1 - 30 mm) · Installation in concrete pots possible · On/Off control gear with luminaire cable pre-assembled for easy installation · Suitable for through-wiring · Can be used in central battery emergency lighting systems in accordance with EN61347-2-13 Annex J · This product contains a light source of energy efficiency class C

Technical data

Unit Code pcs
BAR code 4012094185569
Housing colour weiß RAL9016
Height 85.00 mm
Outer diameter 207 mm
Hole size 195 mm
Depth in ceiling 85.00 mm
LED colour ca. 4000K neutralweiß
Lightoutput per fixture 3540.00 lm
Lamp including LED
IP rating 20
Power 18-24 W
Psb 0,00 W
Current mA 500-700 mA
Voltage 220-240 V
Lamp base ohne
Material Aluminium
Temperature range -20 - 50
CRI ≥ 80
Lifetime L70B50 60.000 h
Lifetime L90B10 42.000 h
Suitable light source
