Einfarbig,Select,RGB,RGBW Master Funkempf.12-48V 240W/480W
Article nr.: 80450-V2
The RF receiver is able to control 1-4 coloured LEDs · The synchronization of the RF receiver takes place via 3-pole data bus, · which can be led up to 30 m from controller to controller · for indoor use · Material: plastic · IP20 · Protection class III, CE, RoHS, REACH · Input voltage: 12 V - 48 V DC · Power: 4 x 60 W at 12 V / 4 x 120 W at 24 V / 4 x 180 W at 36 V / 4 x 120 W at 48 V · output current: 4 x 5A at 12-36V / 4 x 2.5A at 48V · Carrier frequency: 868 MHz · Maximum cable cross-section at terminal: 1.5 sq mm · Synchronization via 3-pole data bus · with memory effect · up to 8 hand transmitter can be saved · Potential free contact for switching and dimming (only for single color)
